Product Overview

Tri-Star CT

For higher volume on-premise laundries with limited space, TRI-STAR CT all-in-one ironer finishing systems are offered in a choice of 32", 28" or 24" (800 mm, 700 mm, or 600 mm) ironing roll diameters. Each all-in-one unit has a built-in CHI controlled primary folder, crossfolder, and stacker that provides complete finishing of up to 800 pounds (360 kg) per hour in less than half the floorspace of a separate ironer and folder. The optional built-in O.P.L. spreader / feeder for large pieces and multi-lane folding for small pieces is also available.

After traveling through the dryer and ironer, linen moves directly into the primary fold section where one or two primary folds are performed by timed air pulses. The crossfold section and stacker / conveyor are identical to those found on the Skyline large piece folder series featuring self-contained motor drives for improved efficiency and reduced maintenance. Chicago’s exclusive air jet crossfolding eliminates the punch blade at the third crossfold. A neatly crossfolded package with hidden selvage edges is delivered to the left side receiving shelf or in adjustable height stacks on the optional automatic stacker with conveyor.

Our all in one ironer provides the same quality you’d expect from one of our separate units, but provides the space saving convenience of a combination machine.
